Our Mobilgrease XHP™ 681 Mine grease is designed for the lubrication of extra-heavy-duty off-highway and mining equipment. It is specially formulated with lithium-complex technology to provide:
- Exceptional staying power
- Water washout and spray-off resistance
- Extended service capabilities
- Compatibility with conventional sealing materials
This grease adheres to surfaces, preventing rainwater and dredging operations from washing it away, and helps to ensure proper lubrication and equipment protection even in some of the most severe water-exposure mining industry conditions.
Data sheets
Product information
Features and Benefits
Mobilgrease XHP 681 is a leading member of the Mobilgrease brand of products, which has gained a reputation world-wide for innovation and performance excellence. Mobilgrease XHP greases are state-of-the-art products designed by our formulation technologists and backed by our world-wide technical support staff.
A key factor in the excellent adhesion and cohesion properties and high drop point of Mobilgrease XHP 681 is the proprietary manufacturing technology developed at our research facilities and adopted by our modern manufacturing facilities. These products use specially selected additives to provide excellent oxidation stability, rust and corrosion control, resistance to water contamination as well as anti-wear and EP protection. Mobilgrease XHP 681 offers the following features and potential benefits:
|
Features |
Advantages and Potential Benefits |
|
Superb resistance to water washout and spray-off |
Helps assure proper lubrication and protection even in the most severe water exposure conditions |
|
Highly adhesive and cohesive structure |
Excellent grease tenacity helps reduce leakage and extend re-lubrication intervals for reduced maintenance requirements. |
|
Excellent rust and corrosion resistance |
Helps protect lubricated parts even in hostile aqueous environments, especially acidic water |
|
Very good resistance to thermal, oxidative and structural degradation at high temperature |
Extended grease life and enhanced bearing protection in high temperature applications helps reduce maintenance and replacement costs. |
|
Very good anti-wear and EP performance |
Provides reliable protection of lubricated equipment, even under conditions of high sliding and shock loading with potential for extended equipment life and reduced unanticipated downtime |
Applications
Mobilgrease XHP 681 Mine is designed primarily for use in the mining industry where it is recommended by ExxonMobil for the lubrication of slow moving plain and rolling element bearings. It will provide extraordinary performance in contractor, construction, earthmoving, mobile and stationary equipment particularly where long lubrication intervals or oscillating/vibrating motion is present.
Properties and Specifications
|
Property |
|
|
Grade |
NLGI 1 |
|
Thickener Type |
Lithium Complex |
|
Base Oil Viscosity of Greases @ 40 C, mm2/s, AMS 1697 |
680 |
|
Color, Visual |
Gray |
|
Copper Strip Corrosion, Rating, ASTM D4048 |
1A |
|
Corrosion, Bearing, Rating, ASTM D1743 |
PASS |
|
Dropping Point, °C, ASTM D2265 |
280 |
|
Four-Ball Extreme Pressure Test, Load Wear Index, kgf, ASTM D2596 |
91.5 |
|
Four-Ball Extreme Pressure Test, Weld Load, kgf, ASTM D2596 |
620 |
|
Four-Ball Wear Test, Scar Diameter, 40 kg, 1200 rpm, 1 h, 75 C, mm, ASTM D2266 |
0.5 |
|
Oil Separation, 24 h @ 25 C, mass%, ASTM D1742 |
2 |
|
Oxidation Stability, Pressure Drop, 100 h, kPa, ASTM D942 |
20.7 |
|
Penetration Consistency Change, Roll Stability, %, ASTM D1831 |
+10 |
|
Penetration, 60X, 0.1 mm, ASTM D217 |
325 |
|
Penetration, Worked, Change from 60X to 100,000X, 0.1 mm, ASTM D217 |
+10 |
|
US Steel Mobility @ 20 F, g/min, AMS 1390 |
11 |
|
Water Resistance, 3 h @ 90 C, Rating, DIN 51807-1 |
0 |
|
Water Sprayoff, Loss, %, ASTM D4049 |
38.7 |
|
Water Washout, Loss @ 79 C, wt%, ASTM D1264 |
2.5 |
Health and safety
Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
- Corrosion protection
- Enhanced wear protection
- Extended life
- Extreme pressure
- High temperature
- Lithium complex
- Low temperature
- Severe operating conditions
- Water resistance
