Mobil SHC Gear Series
Gear Oils
Our Mobil SHC™ Gear synthetic gear oils protect industrial gearboxes and help extend oil life in some of the most extreme conditions. They are formulated for efficient lubrication of industrial enclosed gear drives operating under extreme conditions of load, speed and temperature.
Testing indicates these oils significantly reduce energy consumption in many gearboxes – up to 3.6 percent* versus conventional oil. These synthetic gear oils also:
- Offer excellent compatibility with gearbox metallurgy
- Protect against scuffing and micropitting
- Offer excellent rust and corrosion protection
- Work well in fine filtration, even when wet
-
Long drain intervals help minimize downtime
-
Exceptional protection, even in extreme conditions, helps limit maintenance
-
Minimize maintenance through exceptional protection, even in extreme conditions
Add up your savings
Use our calculator tools to estimate your operation’s potential savings for upgrading your conventional lubricant to Mobil SHC™ oil or grease. Then contact an ExxonMobil engineer or authorized dealer to further refine your estimate.
Use calculatorProduct series information
{0} offers {1} lubricant grades
<%= raw.productdescription%>
<%= raw.marketindustrialproducttypeandfeature %> <% } else { %> <%= title ? title : '' %>
<%= raw.productdescription%>
<%= raw.marketindustrialproducttypeandfeature %> <% } %>
Technical resources
Features and Benefits
Mobil SHC Gear Series lubricants are part of the Mobil SHC line of products that are recognized and appreciated around the world for innovation and outstanding performance. These synthetic products, pioneered by our research scientists, symbolize the continuing commitment to using advanced technology to provide lubricants with excellent balanced performance. A key factor in the development of Mobil SHC Gear Series was the close contacts between our scientists and application specialists with key OEMs to ensure that our product offering would provide exceptional performance with rapidly evolving industrial gear designs and operation. Not least among the benefits shown in work with OEMs is the ability to resist micropitting wear which can occur with some highly loaded, case-hardened gearing applications. This cooperative work also demonstrated the all-round balanced performance benefits for the new Mobil SHC Gear technology, including a wide temperature range of application.
To address the issue of micropitting wear, our product formulation scientists designed a proprietary combination of additives which would resist traditional gear wear mechanisms as well as protecting against micropitting. Mobil SHC Gear products provide exceptional oil life and deposit control and resistance to thermal/oxidative and chemical degradation, as well as the balance of the performance features. The patent-pending combination of synthetic base oils also provides exceptional low temperature fluidity characteristics unmatched by conventional mineral oil gear lubricants and is a key benefit for remote, low ambient temperature applications. The Mobil SHC Gear Series lubricants offer the following potential benefits:
|
Features |
Advantages and Potential Benefits |
|
Superb protection from micropitting fatigue wear as well as high resistance to traditional scuffing wear |
Helps extend gear and bearing life in enclosed gear drives operating under extreme conditions of load, speed and temperature Helps reduce unplanned downtime; less maintenance - especially critical for difficult to access gearboxes. |
|
Excellent resistance to degradation at high temperatures |
Helps extend oil life and drain intervals and reduce oil consumption, which can lower maintenance costs |
|
Low traction |
Helps reduce energy consumption and lower operating temperatures |
|
High viscosity index equating to reduced viscosity change with temperature |
Ability to operate at both high and low temperatures: especially critical in remote applications with no oil cooling or heating |
|
Excellent resistance to rust and corrosion and very good demulsibility |
Helps to ensure smooth, trouble-free operation at high temperatures or in applications subject to water contamination Excellent compatibility with a variety of soft metals |
|
Excellent shear stability |
Helps extend gear and bearing life |
|
Resistence to filter plugging, even in the presence of water |
Fewer filter changes; which can help reduce maintenance costs |
|
Excellent seal compatibility |
Less contamination and lower potential for oil leakage |
|
Excellent compatibility with common gearbox materials and with mineral-based gear oils |
Easy changeover from many mineral products |
Applications
Application Considerations: While the Mobil SHC Gear Series are compatible with mineral oil based products, admixture may detract from their performance. Consequently it is recommended that before changing a system to one of the Mobil SHC Gear Series, it should be thoroughly cleaned out and flushed to achieve the maximum performance benefits.
Mobil SHC Gear Series exceptional performance, synthetic industrial gear oils are designed to provide optimum equipment protection and oil life even under extreme conditions. They are especially formulated to resist micropitting of modern, case hardened gearing and can operate in both high and low temperature environments. Typical applications include:
• Modern, highly loaded gearboxes used in the paper, steel, oil, textile, lumber and cement industries where gear protection and optimum oil life are required.
• Plastic extruder gearboxes
Mobil SHC Gear Series ISO VG 150, 220, 320, 460 and 680 are approved under General Electric's (GE) gear oil specification D50E35 for use in off-highway vehicle motorized wheel gearbox applications.
Specifications and Approvals
|
This product has the following approvals: |
150 |
220 |
320 |
460 |
680 |
1000 |
|
Flender |
X |
X |
X |
X |
X |
|
|
GE OHV D50E35A/B/C/D/E |
X |
X |
X |
X |
X |
|
|
SEW-Eurodrive |
X |
X |
X |
X |
X |
X |
|
ZF TE-ML 04H |
X |
|
|
|
|
|
|
This product meets or exceeds the requirements of: |
150 |
220 |
320 |
460 |
680 |
1000 |
|
AGMA 9005-F16 |
X |
X |
X |
X |
X |
|
|
DIN 51517-3:2018-09 |
X |
X |
X |
X |
X |
X |
|
ISO L-CKD (ISO 12925-1:2024) |
X |
X |
X |
X |
X |
X |
|
ISO L-CTPR (ISO 12925-1:2024) |
X |
X |
|
|
|
|
Properties and Specifications
|
Property |
150 |
220 |
320 |
460 |
680 |
1000 |
|
Grade |
ISO 150 |
ISO 220 |
ISO 320 |
ISO 460 |
ISO 680 |
ISO 1000 |
|
Brookfield Viscosity @ -17.8 C, mPa.s, ASTM D2983 |
|
|
|
|
41000 |
96000 |
|
Brookfield Viscosity @ -29 C, mPa.s, ASTM D2983 |
18200 |
35000 |
57000 |
107000 |
156000 |
500000 |
|
Copper Strip Corrosion, 24 h, 121 C, Rating, ASTM D130 |
1B |
1B |
1B |
1B |
1B |
1B |
|
Demulsibility, Total Free Water, for EP Oils, ml, ASTM D2711 |
88 |
87 |
85 |
84 |
87 |
82 |
|
Density @ 15.6 C, g/ml, ASTM D4052 |
0.86 |
0.86 |
0.86 |
0.86 |
0.86 |
0.87 |
|
Emulsion, Time to 37 mL Water, 82 C, min, ASTM D1401 |
10 |
10 |
10 |
15 |
25 |
40 |
|
FZG Micropitting, Fail Stage, Rating, FVA 54 |
10 |
10 |
10 |
10 |
10 |
10 |
|
FZG Micropitting, GFT-Class, Rating, FVA 54 |
High |
High |
High |
High |
High |
High |
|
FZG Scuffing, Fail Load Stage, A/16.6/90, ISO 14635-1(mod) |
|
>14 |
>14 |
>14 |
>14 |
>14 |
|
FZG Scuffing, Fail Load Stage, A/8.3/90, ISO 14635-1 |
>14 |
|
|
|
|
|
|
FZG Scuffing, Fail Load Stage, A/8.3/90, ISO 14635-1(mod) |
|
14 |
14 |
14 |
14 |
14 |
|
Flash Point, Cleveland Open Cup, °C, ASTM D92 |
233 |
233 |
233 |
234 |
234 |
234 |
|
Foam, Sequence II, Stability, ml, ASTM D892 |
0 |
0 |
0 |
0 |
0 |
0 |
|
Foam, Sequence II, Tendency, ml, ASTM D892 |
0 |
0 |
0 |
0 |
0 |
0 |
|
Four-Ball Extreme Pressure Test, Load Wear Index, kgf, ASTM D2783 |
51 |
51 |
51 |
51 |
51 |
51 |
|
Four-Ball Extreme Pressure Test, Weld Load, kgf, ASTM D2783 |
200 |
200 |
200 |
200 |
200 |
200 |
|
Kinematic Viscosity @ 100 C, mm2/s, ASTM D445 |
22.2 |
30.4 |
40.6 |
54.1 |
75.5 |
99.4 |
|
Kinematic Viscosity @ 40 C, mm2/s, ASTM D445 |
150 |
220 |
320 |
460 |
680 |
1000 |
|
Pour Point, °C, ASTM D5950 |
-54 |
-45 |
-48 |
-48 |
-42 |
-33 |
|
Rust Characteristics, Procedure B, ASTM D665 |
PASS |
PASS |
PASS |
PASS |
PASS |
PASS |
|
Total Acid Number, mgKOH/g, ASTM D664 |
0.9 |
0.9 |
0.9 |
0.9 |
0.9 |
0.9 |
|
Viscosity Index, ASTM D2270 |
176 |
180 |
181 |
184 |
192 |
192 |
Health and Safety
Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
